echarts阶段仪表图

echarts阶段仪表图 – 效率图

1、先上效果展示

在这里插入图片描述

2、完整源码奉上

Vue2 + echarts 5

<template><div ref="gaugeChart" style="width: 100%; height: 100%"></div>
</template><script>
import * as echarts from "echarts";
export default {name: "HomeGaugeChart",data() {return {gaugeChart: null,};},props:{value:{type:String,default:0}},methods: {//初始化方法initChart() {this.gaugeChart = echarts.init(this.$refs.gaugeChart);const option = {tooltip: {formatter: "{a} <br/>COP : {c}",},series: [{name: "冷站效率",type: "gauge",min: 2.5, //最小起始值max: 7, //最大值splitNumber: 45,axisLine: {show: true, // 是否显示仪表盘轴线(轮廓线),默认truelineStyle: {color: [ // 阶段范围对应不同颜色[0.22, "#f44f56"],[0.35, "#f0c537"],[0.55, "#0fbc79"],[1, "#0685d2"],],width: 8,},},title: {fontWeight: "bolder",fontSize: 18,color: "#000",offsetCenter: [0, "80%"],},pointer: {itemStyle: {color: "auto",},},axisTick: {show: false,length: 1,splitNumber: 1,lineStyle: {color: "auto",},},splitLine: {show: true,length: 10,lineStyle: {color: "auto",},},axisLabel: {show: true, // 是否显示标签,默认 true。distance: 10, // 标签与刻度线的距离,默认 5。color: "#000", // 文字的颜色,默认 #fff。fontSize: 12, // 文字的字体大小,默认 5。formatter: function (value) { // 自定义渲染刻度值var arr = [2.5, 3.5, 4.1, 5, 6, 7];if (arr.indexOf(value) > -1) {console.log(value);return value;}},},detail: {valueAnimation: true,formatter: "{value}",color: "inherit",},data: [{ value: this.value, name: "冷站效率" }],  //数据},],};this.gaugeChart.setOption(option);},},mounted() {this.initChart();},
};
</script>
